HR MAX™ 125° 1/2 ” Overlay Cam Adjustable Self-Close Face Frame Hinge with Dowels

HR MAX™ 125° 1/2 ” Overlay Cam Adjustable Self-Close Face Frame Hinge with Dowels

Original price was: $1.92.Current price is: $0.51.

SKU: riabxvxl63317 Category: Cabinet Hinges Tag: Hardware Resources

Description
Reviews (0)

Description

HR Max = Quality backed by Lifetime warranty

125° Robust die cast face frame plate securely grasps the frame and provides two attachment points

One piece 6-way adjustable compact assembly with vertical, horizontal, and depth cam adjustment

Patented dual pivot point

Grade 2 ANSI/BHMA certified to ANSI 50,000 cycles

Features:

Dual Pivot Point brings the door closer to the cabinet reducing door gap.
-Kamaldudu-6 x 5/8\” pan washer head screw (6X258017Q) recommended

Specifications:

Closing	Self-close
Hinge Cup Bore Depth	12.5 mm
Hinge Type	Compact
Mount Centers	45 mm
Recommended Screws	#6 x 5/8\” pan washer head screw (6X258017Q)
Cabinet Type	Faceframe
Pivot Type	Dual
ADA Friendly	No
Packaging Type	Small Package
Degree of Opening	125°
Overlay	1/2\”
Adjustment Type	Cam
Sold By	Each
Brand	HR Max
Series	22855
Finish	Zinc
Hinge Cup Diameter	35 mm
Hinge Dowels	Press-in
Material	Steel
Patent	7594300
Certification	ANSI/BHMA A156.9-2015, ANSI/KCMA A161.1-2012
Installation	Screw Expanding Dowel
Mount Type	Press-in
Warranty Period	Limited Lifetime
